A Compact Holodeck Built From Layered Light, Edge AI, and Body Locomotion
The MyAi 8x8 Immersive Edge Room combines a rear COB fine-pitch LED wall, a forward transparent LED plane, AR glasses, a KAT Walk C2+ treadmill, and a distributed Jetson edge AI cluster — creating strong volumetric depth without projectors.
A Volumetric Illusion System Without Projectors
The MyAi 8x8 Immersive Edge Room is a compact holodeck-inspired system for premium gaming, experiential simulation, and high-value productivity applications. The design combines a rear COB fine-pitch LED wall, a forward transparent LED glass plane spaced 2 to 4 feet in front, AR glasses for depth-of-field overlays and 3D characters, a KAT Walk C2+ locomotion interface, and a distributed Jetson edge AI control cluster.
The system creates strong volumetric depth cues without projectors while remaining commercially practical and scalable for conference rooms, executive suites, venues, and training environments.
Five Functional Elements in an 8x8 Enclosure
The design can be implemented in a minimal form using just the rear wall and front transparent plane, then expanded later to floor and ceiling surfaces — keeping the first build small enough to be practical while preserving a strong holodeck-like illusion.
01
Rear COB LED Wall
A high-luminance, high-contrast background plane using ultra-fine-pitch indoor COB panels for close viewing sharpness and low seam visibility.
02
Transparent Front Plane
A transparent LED film or glass plane mounted 2 to 4 feet in front of the rear wall — carrying foreground layers, floating UI, and partially transparent objects.
03
Optional Enclosure
Side, floor, and ceiling surfaces can be added later for full-enclosure effects, treated as secondary visual planes.
04
AR Glasses
Eye-tracked heads-up overlays, object labels, and 3D character renders at a perceived focal distance that complements the physical display stack.
05
Jetson Edge AI Cluster
Jetson Orin Nano nodes manage rendering, sensing, synchronization, and AI character behavior — locally, privately, offline-capable.
Depth From Layer Separation, Contrast, and Parallax
The COB wall supplies a high-luminance, high-contrast background plane. The transparent front plane appears to float in front of it because viewers see through portions of the display and perceive the physical gap between surfaces. Transparency, spacing, and background composition are the major determinants of visual quality.
AR glasses add another layer of depth realism — eye-tracked heads-up overlays, object labels, and character renders at a perceived focal distance that complements the physical display stack. The result is not a literal hologram, but a convincing volumetric illusion system that is far easier to deploy commercially.
Four Layered Planes
Each plane is engineered to keep latency low enough that the room feels responsive and spatially coherent — with distributed edge compute supporting local privacy, offline operation, and modular scaling.
Display Layer A — Rear COB Wall
Ultra-fine-pitch indoor COB LED panels
Conference-room-class viewing distances
High contrast, close viewing sharpness
Low seam visibility, stable color reproduction
Display Layer B — Transparent Front Plane
Transparent LED film or transparent LED glass
Mounted on optically clear plexiglass or low-iron acrylic
Carries foreground layers, floating UI, semi-transparent objects
Rear wall still functions as deep background
Compute Layer — Jetson Edge
Scene slicing and layer-specific frame generation
Object and person tracking
AR synchronization
Voice interaction and local AI character control
Low-latency, modular, offline-capable
Interaction Layer
AR glasses for depth-of-field and HUDs
KAT Walk C2+ treadmill for body locomotion
Camera arrays and microphone arrays
Optional depth sensors
Spatial audio loudspeakers or DSP
An 8x8 Footprint With Precision Spacing
8x8 footprint — compact for premium installations, large enough for body movement
Transparent plane placed 2–4 ft in front of the COB wall via rigid framing and precision spacers
Service access panels for panel replacement
Optical cleanliness and cable separation
Thermal management for sustained load
Safe user movement around the treadmill and display surfaces
Four Containerized Services
The scene graph lets the same object render differently on the rear wall, the front transparent plane, and the AR glasses. This is the core of the system's volumetric illusion.
01
Scene Orchestration
A unified scene graph that lets the same object render differently on the rear wall, the front transparent plane, and the AR glasses.
02
Edge Rendering
Jetson nodes generate layer-specific frames for each display surface in the stack.
03
Tracking & Occlusion
Camera and depth sensing drive real-time occlusion and spatial coherence.
04
Voice & Character Control
Local AI characters, voice interaction, and behavior modeling on the edge.
Four Procurement Categories
Display
COB fine-pitch LED wall panels, transparent LED film or glass, optically clear plexiglass or low-iron acrylic substrates, spacer frame and mounting rails, LED controllers, power supplies, cabling, thermal and service access hardware.
Compute
Jetson Orin Nano nodes, optional orchestration server, storage, network switch, ethernet cabling.
Interaction
AR glasses, KAT Walk C2+ treadmill, camera array, microphone array, spatial audio speakers or DSP.
Room Infrastructure
UPS, lighting control, HVAC support, safety barriers, floor finish and cable routing, optional enclosure treatment for wall, floor, and ceiling surfaces.
Three Build Tiers
MSRP includes hardware, installation, calibration, software, and warranty reserve.
Prototype
Build Cost
$40k–$90k
Suggested MSRP
$99k–$149k
Lean proof of concept.
Commercial
Build Cost
$90k–$180k
Suggested MSRP
$175k–$299k
Polished commercial demo room.
Flagship
Build Cost
$200k–$400k+
Suggested MSRP
$350k–$650k+
Premium flagship build.
Financed Through MyAi Finance
A managed immersive platform — not just a hardware sale. Lease terms support an optional buyout at end of term.
$100k MSRP
$2.5k–$4k / mo
$200k MSRP
$4.5k–$7.5k / mo
$500k MSRP
$10k–$18k / mo
Lease Terms
36-month lease
48-month lease
60-month lease
Optional buyout at end of term
Optional Service Bundle
Remote monitoring
Hardware maintenance
Content refresh
Treadmill support
AR glasses support
Annual software upgrades
The System Combinations Are the Invention
The strongest patentable concepts are the system combinations and methods, not the component technologies individually.
A compact 8x8 room using a rear COB wall and a forward transparent LED plane
Fixed spacing of 2 to 4 feet between planes to create depth and perspective
Jetson-controlled depth slicing across the two display layers
Synchronized AR glasses overlays adding depth-of-field cues and 3D characters
A projectorless volumetric experience method
A locomotion-integrated immersive room using a VR treadmill
A Distinct Experiential Identity
Premium Gaming
Private immersive gaming rooms with body locomotion and layered depth.
Executive Demo
High-impact executive and client demonstration spaces.
Corporate Training
Experiential simulation and skills training environments.
Immersive Presentation
Pitch and presentation surfaces with real perceived depth.
Retail & Venue
Showcase installations and high-traffic experiential activations.
HNW Entertainment
Personal entertainment rooms for high-net-worth owners.
Conclusion
A Premium Gaming Environment and a High-Value Productivity Room in One
The MyAi 8x8 Immersive Edge Room reduces dependence on projectors, simplifies mechanical complexity, and creates a strong depth illusion through physically separated display layers and synchronized rendering. Full technical brief, line-item BOM, and lease term sheet — available on request for qualified procurement teams.
